Φ1219 China Hot Pipe Bending Machine

Φ1219 China Hot Pipe Bending Machine

Product introduction

     Equipment Specifications:
    1.Production Range:OD60mm-2000mm(2-80 inches)
    2.Radius: 2D≤R≤10D≤15000mm
    3.Thickness:2mm-90mm
    4.Angle:0-180 degree
    5.Material: Carbon Steel, Alloy steel, Stainless Steel
    Our hydraulic automatic induction pipe bending machine has won the national patent, with No.200620128117.9 .
    Bending machine uses PLC control system: input the parameters of pipe OD, wall thickness ,No., material , radius, bending angle ,heating temperature in the touch, PLC will control the heating temperature almost constant (±20°) by closed loop between pushing speed and heating temperature.
   The induction bending machine has already obtained the CE certification.

Detailed introduction Technical parameters
