How Does The Hydraulic Pipe Bending Machine Operate? 返回首页

Pipe Bending Machine can be roughly divided into CNC pipe bending machines, hydraulic pipe bending machines and so on. It is mainly used for electric power construction, public railway construction, pipeline laying and repair of boilers, bridges, ships, furniture, decoration, etc. It has many advantages such as multi-function, reasonable structure and simple operation. In addition to the function of bending the pipe, the machine can also be used as a hydraulic jack. Compared with the numerical control elbow device, it has the advantages of low price and convenient use, and it occupies the leading position in the pipe bending machine market.


Hydraulic Pipe Bending Machine, a new type of pipe bending tool with a curved pipe function and a topping function. It has many advantages such as reasonable structure, safe use, convenient operation, reasonable price, fast loading and unloading, easy to carry, and multi-purpose. It has a large share in the domestic hydraulic pipe bending machine, mainly used in factories, warehouses, docks, buildings, Installation of pipelines and repairs for railways, automobiles, etc. In addition to the elbow function, it can also remove the elbow component (cylinder) as a separate hydraulic hoist. Processing of metal pipe products in industries such as automobiles, motorcycles, sports fitness equipment, steel pipe furniture, travel and leisure products, air conditioning, petrochemicals, plumbing and sanitary ware, and aerospace.


So what should the hydraulic bender pay attention to when using it? We tell you as a Hydraulic Press Manufacturer. First let's take a look at the characteristics of the hydraulic pipe bender:


Hydraulic Pipe Bending Machine

Hydraulic Pipe Bending Machine


1. The pipe bending machine adopts the touch screen plus numerical control module, and the dialogue operation makes the program setting easy and easy.

2. The bed structure is stable and not easy to deform.

3. 16 bend angles can be set for each file, and 16 files can be stored in the memory.

4, all slow positioning function, the angle of the bend is stable, the repeatability is ±0.1°

5. The error message is displayed on the screen to help the operator to eliminate it immediately.

6. Provide self-developed coordinate conversion elbow processing value, and the software can be installed and edited on the desktop computer.


Therefore, the operation of the hydraulic pipe bending machine should be done carefully:


1. When the machine is started, pay attention to the human body not to enter the range of the swivel rotation.

2. When the machine is working, all personnel are prohibited from entering the space range where the boom and pipe fittings are swept!

3. The hydraulic system of the machine tool adopts YA-N32 ordinary hydraulic oil (original grade No. 20). It is replaced once a year under normal conditions, and the oil filter must be cleaned at the same time.

4. When adjusting the machine tool (mold), the adjuster should adjust the button by pressing the button. Never adjust one on the machine and the other on the control cabinet.

5. Remove the core rod when adjusting the machine or emptying the vehicle.

6, the hydraulic system pressure can not be greater than 14Mpa.

7. When manually adjusting the speed of the side push cylinder, the arm should be rotated to ≥900 for adjustment. The adjustment speed is the line speed synchronization of the edge of the elbow bending elbow mold. It is forbidden to push the pushing speed faster than the edge of the rotating mold in the manual state. speed.

8. After using the machine for a period of time, check the tightening degree of the chain and keep the upper and lower chains tight.

9. In the core bending mode during automatic operation, before returning the bending arm, the operator must ensure that the core is inside the pipe, or ensure that the mandrel does not block when the bending arm returns. Otherwise, the core or the core may be Bend or break.


After the final work, cut off the power supply and do the cleaning and lubrication work.


The above is about the use of hydraulic pipe bending machine, I hope to be helpful to everyone. If you are interested in hydraulic pipe bending machines, you can contact us and we can provide you with a good quality pipe bending machine.
